Binary Tree representation using Array:

a Binary Tree T can be represented by Array in 2 different way;

1. Sequential representation (via singular linear array)
2. Linked representation

Sequential representation:
if T is a complete Binary tree, then its-

• root R will be stored in array element T[0]
• if K number of node occupies, will be stored in array element T[K]
• left child will be stored in array element T[ 2*K ]
• right child will be stored in array element T [ 2*K+1 ]

** if T[ 1 ] = NULL, then it is an empty Tree.

diagrammatic explanation:

Linked representation:
if K is the correspond  location pointer :

• need 3 parallel array INFO, LEFT and RIGHT
• data at node N will be stored in array element INFO[K]
• location of left child of node N will be stored in array element LEFT[ K ]
• location of right child of node N will be stored in array element RIGHT [ K ]
• root R of T will be stored in ROOT

diagrammatic explanation:
